Product Details:
Payment & Shipping Terms:
|
| Type: | 3012-700 | Salt Rejection Rate: | 95% |
|---|---|---|---|
| Capacity: | 700GPD | Warranty: | 3 Years |
| Weight: | 0.55KG | Working Up: | 1000TDS |
| Recovery: | 50% | Function: | Water Purification Plant |
| Highlight: | Large Flow High Recovery RO Membrane 700 GPD,High Recovery RO Membrane Element 700 GPD,high recovery ro system 700 GPD |
||
700GPD Large Flow with High Recovery Rate RO Membrane Element for RO System
Reverse osmosis membranes can be used for a variety of fluid separations. Currently, the most widely used reverse osmosis membranes are cross-linked aromatic polyamide reverse osmosis membranes. Usually, m-phenylenediamine and trimesoyl chloride are used for interfacial polycondensation on the surface of porous polysulfone supported membranes. A polyamide layer is formed. The polyamide layer obtained by the reaction is the key to influence the water permeability and salt retardation rate. Therefore, focusing on the interfacial polycondensation reaction and optimizing the polyamide layer in order to obtain a reverse osmosis membrane with large flux and high salt removal rate has always been the direction of many researchers.
Performance and test conditions
| Model | Average Permeate Flow GPD(m³/) | Stable Desalination Rate % |
| BW-3012-700 | 700(2.65) | 95 |
Note: Single membrane permeate flow change in the range of ±15%
Test Conditions
Test Pressure 100psi( 0.7Mpa)
Temperature 25ºC
Concentration of Testing Solution (NaCl) 500ppm
Testing Solution PH 2-11
Note:1. The Max. continous operation temperature is 35ºC when PH rate over 10.
2. In certain conditions,if would cause membrane breakage if the free chlorine or the other oxidant in feedwater.The production quality guarantee range is notincluded membrane breakage by oxiadation.
Dimension of Membrane Element
3012-700: A:12.0mm B:3.0mm C:0.68mm D:0.75mm E:10mm
HN-JCM brand membrane element produced by world advanced membrane technology and fully automatic production equipment. It can operation under the extra low pressure. Our membrane suitable for household water purifiers, hospitals, laboratory pure water, treatment municipal tap water, well water and other low salinity water sources.
