Brackish Water Ro Membrane For High Tds Water 10000 Tds Membrane 8 Inch

Product Summary
8-inch Reverse Osmosis Membrane for Industrial Brackish Water Treatment RO System RO membranes, in general, remove 90% or more of the contaminants present in the water, including TDS. When the TDS levels of your water source changes, it will affect the quality of the purified water output from your ...
Basic Properties
Place of Origin: CHINA
Brand Name: Purple Horn
Certification: CE, RoHS, ISO9001, NSF
Model Number: 8040-LP
Trading Properties
Minimum Order Quantity: 1
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30000 PCS /Month
Product Description

8-inch Reverse Osmosis Membrane for Industrial Brackish Water Treatment RO System



RO membranes, in general, remove 90% or more of the contaminants present in the water, including TDS. When the TDS levels of your water source changes, it will affect the quality of the purified water output from your reverse osmosis system.



Even though in most circumstances the majority of the dissolved solids in water is salt, the S in TDS stands for solids, and not just salt. A reverse osmosis system uses a semi-permeable membrane to reject dissolved solids and other impurities from water.

There are several possible causes of a high TDS reading from water that's been purified by reverse osmosis: The quality of the water source has changed. The post-filter is adding minerals to the purified water. The rejected water is being re-used (applies to countertop RO systems). The reverse osmosis membrane needs to be replaced.



High TDS from a reverse osmosis system can be caused by the membrane malfunctioning, poor water pressure, a restricted drain line, non-reverse osmosis water contamination, higher TDS going into the reverse osmosis system or re-mineralization of the reverse osmosis water. Therefore, we have developed membrane elements for high TDS environments, normally, can be working up to 5000ppm, some also can be working up to 6000ppm to 8000ppm according to customer's request for high TDS series.



Brackish Water Ro Membrane For High Tds Water 10000 Tds Membrane 8 Inch 0



The product specification

Model Number Description 8040-LP
Performance &
Test Condition
The Desalination Rate % 99.5%
Water Rate GDP 10500
The Test pressure 225psi
Test solution Temperature 25± 1ºC
Test Solution Concentration NaCl 2.0-11.0
Recovery Of Single-Branch Membrane Element 15%
Feed water SDI 5
  • When PH is above 10, the Maximum Temperature of Continuous Operation is 35ºC.
  • Under certain conditions, the presence of free chlorine and other oxidants in the water may cause serious membrane damage, which doesn't belong to product warranty range.

Operating Limit:

Maximum Operating Temperature 113ºF(45ºC)
Maximum Working Pressure 600psi(41.0 bar)
The high pressure drop 15psi (1.0bar)
Continuously operating PH range a 3-10
Short wash PH range (30min) b 2-12
Maximum feed water SDI SDI 5
Tolerance Of Free Chlorine <0.1ppm
Maximum pressure drop for single membrane element 15psi(0.1Mpa)





Dimension of Membrane Element

Brackish Water Ro Membrane For High Tds Water 10000 Tds Membrane 8 Inch 1



PROCEDURES



Brackish Water Ro Membrane For High Tds Water 10000 Tds Membrane 8 Inch 2



FAQ:

Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balanced against the copy of B/L.

Q: What is the delivery time?
A: Usually within 15days. Also depends on order quantities.

Q: Can the package be customized by our own logo ?
A: Yes, the package can be customized your logo, but the MOQ will be higher for which we can discuss as per the specific orders.

Q: How to install after the products arriving destination?
A: We will provide detailed illustrations to you. And we can also provide guide to your workers how to use it and how to maintain
it.

Q:What's the certification do you have?
A: We have NSF, ISO9001, OHSAS18001, ISO14001 Certifications.


Product Details
Highlight:

Brackish Water Ro Membrane 10000 tds

,

ro membrane for high tds water

,

10000 tds membrane

Type: Reverse Osmosis Membrane
Salt Rejection Rate: 99.5%
Capacity: 10500GPD
Recovery Rate: 15%
Operation Pressure: 225psi
Weight: 13.8KG
Warranty: 3 Years
Packing: 1PCS/Carton
Place Of Origin: CHINA
